Hi Rupert, Yes, there is support for an external pause button.

The first set of three pins on the EBB control board above the three pins used for standard pen-lift servo control are, by default, configured to act as an alternate pause button input.

From back to front, those three pins are ground, +5 V out, and signal in. Your external button should be a normally-open button that gives no connection except when you press the button. Wire it from the front pin (signal in) to the back pin (ground), leaving the +5 V pin not connected to anything.

Kind regards, -Windell



https://github.com/evil-mad/EggBot/issues/8

bmaranville - I have created EBB Firmware v2.2.7, which includes a new command called "ES" for you. (E-Stop). Here is the hex file for v2.2.7 so you can update your EBB :
(https://github.com/evil-mad/EggBot/raw/master/EBB_firmware/Releases/app/EBF_v227.zip)
And here is the updated documentation for v2.2.7
(http://www.schmalzhaus.com/EBB/EBBCommands.html)

Please try it out, and see if it works for you.

Windell H. Oskay, Ph.D. Co-Founder and Chief Scientist Evil Mad Scientist Laboratories 1285 Forgewood Ave Sunnyvale, CA 94089 http://www.evilmadscientist.com/



https://www.calligrapher.ai/

Style 9

Style 4

Tiling an object in InkScape

Assembling The AxiDraw MiniKit2



https://revdancatt.com/penplotter/

https://github.com/evil-mad/AxiDraw-Processing Control the plotter directly from Processing

AxiDraw-Processing

https://www.youtube.com/watch?v=hNDN943yTN4

Some simple examples showing how one can control the AxiDraw, directly from within Processing.

Issue reports and contributions welcome.

Two examples are currently included:

AxiGen1: Draw a random walk where you click the mouse. This is a good starting point for making generative artwork on the AxiDraw.

AxiRT: Real-time drawing software for the AxiDraw; a derivative of https://github.com/evil-mad/robopaint-rt You can draw a sketch with your cursor, and the AxiDraw will draw it onto paper.

See also: https://github.com/ralphcrutzen/AxiTurtle, real-time turtle graphics control of AxiDraw, based on these examples.
